Research and Implementation of Automatic Scanning Detection Device for Bandpass Filter Quality

Research and Implementation of Automatic Scanning Detection Device for Bandpass Filter Quality

Citation

刘千顺 (Liu Qianshun). (年 月). 107 带通滤光片质量自动扫描检测装置的研究与实现 [Research and Implementation of Automatic Scanning Detection Device for Bandpass Filter Quality] (硕士专业学位论文) [Master's Professional Degree Thesis]. 浙江大学 [Zhejiang University].

Keywords

  • 带通滤光片 / Bandpass Filter
  • 质量检测 / Quality Detection/Inspection
  • 自动扫描 / Automatic Scanning
  • 微型光谱仪 / Miniature Spectrometer
  • 二维移动平台 / 2D Moving Platform
  • 透射率 / Transmittance
  • 光谱 / Spectrum/Spectral
  • 步进电机 / Stepper Motor
  • 上位机应用程序 / Upper Computer Application
  • 数据处理算法 / Data Processing Algorithm
  • 噪声去除 / Noise Removal/Reduction
  • 中心波长 / Center Wavelength
  • 峰值透过率 / Peak Transmittance
  • 相对带宽 / Relative Bandwidth
  • 截止深度 / Cut-off Depth

Brief

This thesis focuses on the design and implementation of an automated scanning system for bandpass filter quality inspection using a miniaturized spectrometer and a 2D moving platform.

Summary

This thesis details the design and implementation of an automated system for bandpass filter quality inspection. It uses a miniature spectrometer to measure the transmission spectra of filters mounted on a 2D moving platform controlled by stepper motors. The system features custom software with algorithms for noise reduction and to automatically determine key quality parameters like peak wavelength, center wavelength, bandwidth, and cut-off depth, offering a fast and comprehensive alternative to existing methods.
