LP1580 롱패스 필터(T>95%@1590-1800nm, OD3@400-1570nm)

컷온=1580nm / T>95%@1590-1800nm // OD3@400-1570nm / SM05(0.535-40TPI)
$60.00
할인가  $60.00 정가
제품 정보로 건너뛰기
Transmission spectrum graph with wavelength on the x-axis and transmission percentage on the y-axis.

LP1580 롱패스 필터(T>95%@1590-1800nm, OD3@400-1570nm)

SO3040107

컷온 파장
컷온 파장
컷온=1580nm
전송 // 차단
전송 // 차단
T>95%@1590-1800nm // OD3@400-1570nm
재고 있음
$60.00
할인가  $60.00 정가
연말연시 배송 서비스

맞춤형 크기 요청

결제 방법
  • American Express
  • Apple Pay
  • Discover
  • Google Pay
  • JCB
  • Mastercard
  • Visa
Stock Availability
이 제품을 직접 주문할 수 있습니까?
Custom Size & Mounting
주문제작 사이즈 또는 설치 옵션을 요청할 수 있나요?
Request Raw Data
변환 곡선 또는 스펙트럼 데이터를 요청할 수 있나요?
Shipment & Delivery

We ship optical products to most supported regions, with shipping cost and delivery method confirmed before payment.

Shipping cost
  • Shipping is generally USD 5–40 per parcel
  • Orders above USD 300 are eligible for free shipping
  • Final cost depends on destination, package size, order value, and shipping method
  • Shipping cost is shown during checkout or confirmed before payment
Shipping coverage
  • We generally ship to Europe, North America, Asia, the Middle East, and Oceania
  • Some countries may be unavailable depending on logistics or customs conditions
Delivery time
  • Most stocked products need 1–5 working days for preparation before shipment
  • After shipment, delivery time depends on destination and shipping method
  • Tracking information will be provided when available
Note
  • If your destination is not available during checkout, please contact us before ordering.

Payment & Quotation

You can order online, request a quotation, or use bank transfer depending on your purchasing process.

Can I request a quotation before ordering?
  • Yes, formal quotations are available before payment
  • Recommended for company purchases, larger quantities, custom sizes, or special shipping requirements
  • Please send the product link, quantity, destination country, and billing details if available
What online payment methods are available?
  • Credit card
  • Apple Pay
  • Google Pay
Do you support bank transfer?
  • Yes, bank transfer is available
  • We support multi-currency payment through local banking where available
  • Local receiving accounts may include US, UK, Germany, Singapore, and Hong Kong bank accounts
  • For payment in Chinese RMB inside Mainland China, please contact our local partner
  • VAT fapiao may be supported for eligible Mainland China transactions
Do you support company purchase orders?
  • Company purchase orders may be supported after confirmation
  • Please contact us before ordering if your organization requires PO processing, quotation, or invoice matching
Are NET payment terms available? (Pay after received)
  • NET 7 or NET 30 terms may be available for eligible organizations
  • Approval depends on company type, order value, payment history, and internal review
  • Please contact us before ordering if you need NET payment terms
Import, Duties & Customs
수입 관세 및 세금

전문가용 LP1580 롱패스 필터 - 근적외선 정밀

1580nm 범위에서 정밀한 파장 전송이 필요하고 짧은 파장을 탁월하게 차단해야 하는 애플리케이션을 위해 특별히 설계된 LP1580 롱패스 필터로 뛰어난 근적외선 성능을 달성하세요.

주요 사양:

  • 컷온 파장: 1580nm (T=50%)
  • 높은 전송 범위: T>95% @ 1590-1800nm
  • 우수한 차단성: OD3 @ 400-1570nm

왜 LP1580 필터를 선택해야 할까요?

이 롱패스 필터는 근적외선 분야에서 탁월한 성능을 발휘하여 1590nm 이상에서 탁월한 투과 효율을 제공하는 동시에 가시광선 및 그보다 짧은 근적외선 파장을 효과적으로 차단합니다. 높은 투과율은 목표 파장 범위에서 최대 신호 처리량을 보장하는 동시에, OD3 차단 기능은 원치 않는 짧은 파장을 안정적으로 차단합니다.

이상적인 응용 분야:

  • 근적외선 분광법 및 분석
  • 통신 및 광섬유 시스템
  • 레이저 라인 분리 및 정리
  • 열화상 및 감지
  • 광자공학 연구 개발
  • 산업 공정 모니터링

기술적 장점:

  • 정확한 파장 구별을 위한 가파른 전이 가장자리
  • 우수한 스트레이 라이트 제거를 위한 높은 광학 밀도 차단
  • 전송 범위 전반에 걸쳐 일관된 성능
  • 장기적인 신뢰성을 위한 내구성 있는 구조

첨단 박막 코팅 기술을 사용하여 제조된 이 필터는 중요한 근적외선 응용 분야에 안정적이고 일관된 성능을 제공합니다. 각 필터는 엄격한 광학 사양을 충족하는지 확인하기 위해 포괄적인 품질 테스트를 거칩니다.

유사 대역 통과 필터

제품 FAQ

차단 파장 / 차단 한계 파장

컷온/컷오프 파장은 에지패스 필터가 빛을 투과하기 시작하거나 멈추는 전환 지점입니다. 실제 시스템에서는 어떤 파장 범위가 통과되고 어떤 범위가 감소되거나 차단되는지를 정의합니다.

차단 영역

차단 영역은 필터가 원치 않는 빛을 억제하도록 설계된 파장 범위입니다. 실제 시스템에서는 더 강력하거나 넓은 차단이 배경 신호, 산란광 및 검출기 간섭을 줄이는 데 도움이 됩니다.

광학 밀도 (OD)

차단 깊이 / 광학 밀도(OD)는 차단 영역에서 원치 않는 빛이 얼마나 강하게 억제되는지를 나타냅니다. 예를 들어, OD6 @ 200–1200nm는 필터가 200–1200nm 파장을 약 0.0001% 투과율로 차단하여 미광, 배경 신호 및 감지기 과부하를 줄이도록 설계되었음을 의미합니다.

입사각(AOI)

입사각(AOI)은 빛이 필터 표면에 도달하는 각도입니다. AOI가 증가하면 간섭 필터는 스펙트럼 이동을 보일 수 있으며, 일반적으로 투과 또는 전이 파장이 더 짧은 파장 쪽으로 이동합니다.

이 필터 확인에 도움이 필요하신가요?

기존 부품을 교체하시거나 새 시스템을 구축하시는 경우, 다음 정보를 보내주십시오:
- 원래 부품 번호 또는 목표 사양
- 필요한 크기 및 수량
- 적용 분야 또는 시스템 목표

저희가 제품 적합성을 확인해 드리거나 재고/맞춤형 대안을 제안해 드리겠습니다.
