Reflectance spectrum graph with wavelength on the x-axis and reflectance percentage on the y-axis.

투과율 > 90%@350-392nm + 반사율 > 99%@405nm, 단파장 다이크로익 미러(SPDM398)

T>90%@350-392nm // R>99%@405nm / 직경 12.5mm(장착됨)
$55.00
할인가  $55.00 정가
제품 정보로 건너뛰기
Reflectance spectrum graph with wavelength on the x-axis and reflectance percentage on the y-axis.

투과율 > 90%@350-392nm + 반사율 > 99%@405nm, 단파장 다이크로익 미러(SPDM398)

SO3060504
투과 범위 // 반사 범위
투과 범위 // 반사 범위
T>90%@350-392nm // R>99%@405nm
SO3060504-d12.5mt
재고 있음
$55.00
할인가  $55.00 정가
연휴 배송

맞춤형 사이즈 요청

결제 방법
  • American Express
  • Apple Pay
  • Discover
  • Google Pay
  • JCB
  • Mastercard
  • Visa
Stock Availability

Yes. Listed filters are generally available from stock, but final availability may depend on size and quantity.

  • Most filters are kept as medium-sized coated pieces
  • Final size is usually diced before shipment
  • Preparation time may vary for urgent orders, custom sizes, or larger quantities
Custom Size & Mounting
주문제작 사이즈 또는 설치 옵션을 요청할 수 있나요?
Request Raw Data
변환 곡선 또는 스펙트럼 데이터를 요청할 수 있나요?
Shipment & Delivery
배송에는 보통 얼마나 걸리나요?
Payment & Quotation

You can order online, request a quotation, or use bank transfer depending on your purchasing process.

Can I request a quotation before ordering?
  • Yes, formal quotations are available before payment
  • Recommended for company purchases, larger quantities, custom sizes, or special shipping requirements
  • Please send the product link, quantity, destination country, and billing details if available
What online payment methods are available?
  • Credit card
  • Apple Pay
  • Google Pay
Do you support bank transfer?
  • Yes, bank transfer is available
  • We support multi-currency payment through local banking where available
  • Local receiving accounts may include US, UK, Germany, Singapore, and Hong Kong bank accounts
  • For payment in Chinese RMB inside Mainland China, please contact our local partner
  • VAT fapiao may be supported for eligible Mainland China transactions
Do you support company purchase orders?
  • Company purchase orders may be supported after confirmation
  • Please contact us before ordering if your organization requires PO processing, quotation, or invoice matching
Are NET payment terms available? (Pay after received)
  • NET 7 or NET 30 terms may be available for eligible organizations
  • Approval depends on company type, order value, payment history, and internal review
  • Please contact us before ordering if you need NET payment terms
Import, Duties & Customs
수입 관세 및 세금

이 SPDM398 단파장 다이크로익 미러는 350~392nm의 자외선을 투과하면서 405nm의 장파장을 반사하도록 설계되었습니다.

이 제품은 405nm 보라색 레이저 다이오드 또는 보라색 LED를 사용하는 형광 검출, UV 분광법 및 빔 라우팅 시스템에 적합합니다. 파장에 따라 빔을 분리하여 단파장 UV 신호는 통과시키고 405nm 빛은 반사시켜 컴팩트한 광학 설정에서 여기 광원을 분리하거나 특정 스펙트럼 라인을 관리하는 데 이상적입니다.

주요 사양:

  • 파장/주요 사양: 350~392nm 투과; 405nm 반사
  • 대역폭/전환 사양: 392nm와 405nm 사이의 단파장 다이크로익 전환
  • 투과율/차단율: T >90%(350~392nm); R >99% @ 405nm
  • 형식/맞춤 옵션: 마운트형(직경 12.5~25mm) 및 비마운트형(25x36mm~35x52mm)으로 제공

유사 대역 통과 필터

제품 FAQ

다이크로익 미러는 무엇을 하나요?

다이크로익 미러는 파장에 따라 빛을 분리합니다. 이 미러는 한 파장 범위를 반사하는 동시에 다른 파장 범위를 투과하도록 설계되었습니다.

예를 들어, 다이크로익 미러는 레이저 파장을 반사하는 동시에 가시광선 정렬 빔, 형광 신호 또는 다른 레이저 파장을 투과할 수 있습니다. 정확한 기능은 반사 대역, 투과 대역 및 입사각에 따라 달라집니다.

입사각은 얼마로 해야 하나요?

대부분의 다이크로익 미러는 별도의 명시가 없는 한 특정 입사각, 일반적으로 45°에 맞춰 설계됩니다.

이 이색성 미러는 레이저 빔을 결합하거나 분리하는 데 사용할 수 있습니까?

네. 이색성 미러는 파장이 충분히 다르고 반사/투과 대역이 시스템 요구 사항과 일치할 경우 레이저 빔 결합 및 빔 분리에 일반적으로 사용됩니다.

예를 들어, 한 파장은 45°로 반사되고 다른 파장은 미러를 통과할 수 있습니다. 주문하기 전에 레이저 파장, AOI, 빔 크기 및 필요한 반사/투과 성능을 확인하십시오.

이 제품이 귀하의 설정에 맞는지 확실하지 않으신가요?

기존 부품을 교체하거나 새 시스템을 구축하는 경우 다음을 보내주십시오.
- 원래 부품 번호 또는 목표 사양
- 필요한 크기 및 수량
- 애플리케이션 또는 시스템 목표

저희는 제품 적합성을 확인하거나 재고/맞춤형 대안을 제안하는 데 도움을 드릴 것입니다.

제품 적합성 확인
