T＞90%@450-495nm+R>99%@505-595nm Shortpass Dichroic Mirror(SPDM)

Professional Blue-Green Shortpass Dichroic Mirror - Precision Fluorescence Optics

This high-performance shortpass dichroic mirror provides exceptional wavelength separation in the blue-green spectral region, making it ideal for advanced fluorescence microscopy and multi-wavelength optical systems. Engineered for 45° angle of incidence, this mirror delivers superior spectral control for demanding biological and analytical applications.

Key Specifications:

• Transmission: T>90% @ 450-495nm (Blue region)
• Reflection: R>99% @ 505-595nm (Green-Yellow region)
• Angle of Incidence: 45°
• Mirror Type: Shortpass Dichroic
• Spectral Range: Blue to yellow-green visible spectrum

Applications & Benefits:

• Fluorescence Microscopy: Perfect for FITC, GFP, and Alexa Fluor 488 imaging systems
• Multi-Channel Imaging: Efficient separation of blue excitation from green emission
• Flow Cytometry: Critical component for multi-parameter cell analysis
• Confocal Microscopy: Precise wavelength control for high-resolution imaging
• Laser Systems: Beam combining and separation for blue and green lasers
• Spectroscopy: Wavelength selection for analytical instrumentation

Technical Advantages:

• Ultra-high reflection (>99%) in green region minimizes signal loss
• Excellent transmission (>90%) in blue region preserves excitation efficiency
• Sharp spectral transition at ~500nm for precise channel separation
• 45° angle of incidence optimized for compact optical designs
• Low autofluorescence for sensitive detection applications

Fluorescence Excellence:

• FITC Compatible: Optimized for fluorescein isothiocyanate imaging
• GFP Applications: Ideal for green fluorescent protein visualization
• Multi-Color Systems: Enables simultaneous blue/green channel imaging
• High Contrast: Superior signal-to-background ratio

Quality Features:

• Advanced multi-layer dielectric coatings for superior performance
• Premium optical glass substrate with exceptional surface flatness
• Fluorescence-optimized coatings minimize background interference
• Temperature-stable performance ensures consistent results
• Rigorous spectral testing guarantees performance specifications

Why Choose SyronOptics Blue-Green Dichroic Mirror? Our shortpass dichroic mirrors are specifically engineered for fluorescence applications requiring precise blue-green wavelength separation. With >99% reflection in the green region and >90% transmission in the blue, this mirror is the professional choice for advanced microscopy and analytical systems.

Essential for fluorescence microscopy, flow cytometry, and multi-wavelength imaging systems requiring precise blue-green spectral control.
