T>90%@410-600nm+R>99%@300-390nm Longpass Dichroic Mirror(LPDM)

Visible Spectrum Dichroic Mirror with UV Protection

This precision dichroic mirror features exceptional T>90% transmission from 410-600 nm and R>99% reflection at 300-390 nm, delivering superior performance across the visible spectrum while providing comprehensive UV protection.

Key Features:

• Visible Spectrum Transmission: Greater than 90% transmission from 410-600 nm (violet to orange)
• Complete UV Blocking: Greater than 99% reflection across UV-B and UV-A ranges (300-390 nm)
• Optimal Color Reproduction: Excellent transmission of violet, blue, green, yellow, and orange wavelengths
• UV-A and UV-B Protection: Blocks both harmful UV-A and UV-B radiation
• High-Performance Coating: Advanced multi-layer dielectric design for durability

Applications:

• Color imaging systems and digital cameras
• Fluorescence microscopy with visible excitation
• LED lighting systems and color mixing
• Photographic and cinematographic equipment
• Biological imaging requiring UV protection
• Display technology and projection systems

Ideal for applications requiring accurate color reproduction and UV protection. This mirror ensures your optical systems capture the full beauty of the visible spectrum while safeguarding sensitive components from harmful UV radiation.
